Dedicated distribution unit for the Aquila series heat recovery units, connection of up to 10 ducts
Ø75 mm (5 supply ducts + 5 exhaust ducts). It is used to distribute the supply air and collect used air from rooms connected to the recuperation system
The distribution unit can be combined with the air handling unit or moved to any suitable location and connected by means of ventilation ducts fi160 (version VARR75-160K)
The distribution unit housing is made of EPP (expanded polypropylene), which has a significant effect on the volume level by absorbing vibrations
The product is of the highest tightness class (D), insulating heat perfectly while being stable over a wide temperature range (from -40°C to +60°C). What is more important, expanded polypropylene is not conducive to mould and mildew
The distribution unit is compatible with the left and right versions of the heat recovery unit. The spigot diameter of the unit is Ø160 mm
The distribution unit replaces the traditional distribution box
